KLX®230 S

LIGHTWEIGHT DUAL-SPORT FOR ON- AND OFF-ROAD FUN

  • MSRP NON-ABS
    $4,999
  • /
  • MSRP ABS
    $5,299

Destination Charge $300

Dealer sets the actual destination charge, your price may vary.

Specifications and pricing are subject to change.

Mouse Coordinates:

Difference X: Dragging:

Difference Y:

Color Folder:
txtTouchOffset:
360 Vehicle View
360 degree rotation
Select a Color

Select a View
ABS SYSTEM WITH
ON/OFF FUNCTION
SMARTPHONE CONNECTIVITY
VIA RIDEOLOGY THE APP

Click on a technology to learn more.

Engine Management Technology
Chassis Management Technology
POWER
Engine 4-stroke single, SOHC, air-cooled
Displacement 233cc
Bore x Stroke 67.0 x 66.0mm
Compression Ratio 9.4:1
Maximum Torque 13.2 lb-ft @ 6,400 rpm
Fuel System DFI® with dual 32mm throttle bodies
Ignition TCBI with Electronic Advance
Transmission 6-speed
Final Drive Sealed chain
Electronic Rider Aids Anti-lock Brake System (ABS)
PERFORMANCE
Front Suspension / Wheel Travel 37mm telescopic fork/7.8 in
Rear Suspension / Wheel Travel Uni-Trak® linkage system and single shock with adjustable spring preload/8.7 in
Front Tire 2.75 x 21
Rear Tire 4.10 x 18
Front Brakes Single 240mm (265mm ABS Model) petal disc with a dual-piston caliper (and ABS)
Rear Brakes Single 220mm petal disc with single-piston caliper (and ABS)
DETAILS
Frame Type Perimeter, high-tensile steel
Rake/Trail 24.6°/3.7 in
Overall Length 81.8 in
Overall Width 33.2 in
Overall Height 44.8 in
Ground Clearance 9.4 in
Seat Height 33.2 in
Curb Weight 291.0/293.2 lb* 50-State Model
Fuel Capacity 2.0 gal
Wheelbase 53.7 in
Special Features ERGO-FIT®, LCD Instrumentation with Smartphone Connectivity via RIDEOLOGY THE APP MOTORCYCLE
Color Choices Lime Green, Battle Gray
VIEW WARRANTY INFO DOWNLOAD SPECS

*Curb weight includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied). When equipped, California evaporative emissions equipment adds approximately 2.2 lb.

KAWASAKI CARES: Read Owner's Manual and all on-product warnings. Always wear a helmet, eye protection and proper apparel. Never ride under the influence of drugs or alcohol. Adhere to the maintenance schedule in your Owner’s Manual. ©2024 Kawasaki Motors Corp., U.S.A.

Specifications subject to change.
