56014
56014
56050
56060
56060A
56060B
56060C
Part Item Information
ITEM NAME REF # PART NUMBER QUANTITY DESTINATION REMARKS
EMBLEM,KAWASAKI,FOR GRAY 56014 56014-1267 2
MARK,BAYOU 56050 56050-1844 1
PATTERN,FR FENDER,LH 56060 56060-1289 1
PATTERN,FR FENDER,RH 56060A 56060-1290 1
PATTERN,RR FENDER,LH 56060B 56060-1291 1
PATTERN,RR FENDER,RH 56060C 56060-1292 1
