1997 Prairie 400 4X4 - Gear Change Drum/Shift Fork(s)

13107
13260
13260A
13260B
39135
92022
92033
92033
92033
Part Item Information
ITEM NAME REF # PART NUMBER QUANTITY DESTINATION REMARKS
SHAFT,IDLER 13107 13107-1363 1
GEAR,FORWARD/LOW,24T 13260 13260-1578 1
GEAR,COUNTER HI,37T 13260A 13260-1642 1
GEAR,IDLER,33T 13260B 13260-1671 1
SPROCKET-DRIVEN,33T 39135 39135-1056 1
WASHER,25.3X32X1 92022 92022-1800 1
RING-SNAP,24MM 92033 92033-026 3
