2021 KFX®90 - Gear Change Drum/Shift Fork(s)

DOWNLOAD PDF
SELECT A NEW PART
11061
13107
13234
13271
14026
14055
16085
39134
39159
92033
92043
92043A
92043A
92045
92045
92045A
92049
92055
92057
92153
92154
92200
92200A
92210
Part Item Information
ITEM NAME REF # PART NUMBER QUANTITY DESTINATION REMARKS
GASKET,GEAR CASE 11061 11061-Y016 1
SHAFT,FINAL 13107 13107-Y004 1
SHAFT-COMP 13234 13234-Y001 1
PLATE 13271 13271-Y007 1
COVER-CHAIN 14026 14026-Y001 1
CASE-GEAR 14055 14055-Y001 1
GEAR,FINAL 16085 16085-Y004 1
SPROCKET-DRIVE 39134 39134-Y001 1
SHAFT-DRIVE 39159 39159-Y001 1
RING-SNAP 92033 92033-Y011 1
PIN,BRAKE 92043 92043-Y001 1
PIN,DOWEL,10X20 92043A 92043-Y014 2
BEARING-BALL,6201 92045 92045-Y002 2
BEARING-BALL,6004 UU 92045A 92045-Y005 1
SEAL-OIL,27X42X7 92049 92049-Y008 1
RING-O,7.5X1.5 92055 92055-Y002 1
CHAIN,DRIVE 92057 92057-Y004 1
BOLT,FLANGE,6X10 92153 92153-Y045 2
BOLT,HEX,6X10 92154 92154-Y145 2
WASHER,12MM 92200 92200-Y004 1
WASHER,15MM 92200A 92200-Y007 1
NUT,8MM 92210 92210-Y014 1
