1995 Ninja® ZX™-11 - Battery Case

DOWNLOAD PDF
SELECT A NEW PART
11012
11012
11012
11012
11012
11012
11012A
11012A
11012A
11047
11047
11047
11047
11047
11047
11047A
11047A
11047A
11047B
11047B
11047B
11047C
11047C
11047C
11047D
11047D
11047D
11047F
11047F
11047F
11047G
11047G
11047G
11048
11048
11048
11048A
11048A
11048A
11048B
11048B
11048B
14069
14069
14069
14090
14090
14090
32109
32109
32109
130
130
130
130
130
130
130A
130A
130A
130A
130A
130A
130B
130B
130B
130B
130B
130B
130B
130B
130B
130C
130C
130C
130C
130C
130C
130D
130D
130D
130E
130E
130E
130F
130F
130F
132
132
132
132
132
132
132A
132A
132A
132A
132A
132A
132B
132B
132B
132B
132B
132B
221
221
221
53044
53044
53044
53045
53045
53045
55020
55020
55020
55020A
55020A
55020A
92037
92037
92037
92037A
92037A
92037A
92072
92072
92072
92072A
92072A
92072A
92150A
92150A
92150A
92150A
92150A
92150A
92160
92160
92160
702
702
702
Part Item Information
ITEM NAME REF # PART NUMBER QUANTITY DESTINATION REMARKS
CAP 11012 11012-1460 4
CAP 11012A 11012-1657 2
BRACKET,REAR STAY 11047 11047-1878 2
BRACKET,RADIATOR,UPP,LH 11047A 11047-1931 1
BRACKET,RADIATOR,UPP,RH 11047B 11047-1932 1
BRACKET,IGNITION COIL,LH 11047C 11047-1933 1
BRACKET,IGNITION COIL,RH 11047D 11047-1934 1
BRACKET,SEAT LOCK 11047F 11047-1961 1
BRACKET,HELMET LOCK 11047G 11047-1962 1
BRACKET,OIL COOLER&RADIATOR 11048 11048-1169 1
BRACKET,FUEL PUMP 11048A 11048-1180 1
BRACKET,TAIL GRIP 11048B 11048-1325 1
BREATHER 14069 14069-1054 1
COVER,BATTERY 14090 14090-1305 1
GRIP-FRAME 32109 32109-1233 1
BOLT-FLANGED 130 130J0610 3
BOLT-FLANGED,6X14,BLACK 130A 130J0614 6
BOLT-FLANGED,6X16,BLACK 130B 130J0616 8
BOLT-FLANGED 130C 130J0812 2
BOLT-FLANGED,8X20 130D 130J0820 1
BOLT-FLANGED,8X25,BLACK 130E 130J0825 1
BOLT-FLANGED,8X35,BLACK 130F 130J0835 2
BOLT-FLANGED-SMALL,6X10 132 132J0610 4
BOLT-FLANGED-SMALL,8X12 132A 132J0812 4
BOLT-FLANGED-SMALL 132B 132J0825 2
SCREW-CSK-CROS,6X20 221 221E0620 4
TRIM,L=165 53044 53044-1270 1
HOOK-ASSY,ROPE 53045 53045-1057 4
GUARD,SEAT STRIKER 55020 55020-1498 1
GUARD,SEAT LOCK 55020A 55020-1499 1
CLAMP,TUBE 92037 92037-147 1
CLAMP,HOSE 92037A 92037-1875 1
BAND,L=100 92072 92072-071 1
BAND,BATTERY 92072A 92072-1188 1
BOLT,SOCKET,8X20 92150A 92150-1839 4
DAMPER,ROPE HOOK 92160 92160-1042 4
TUBE-RUBBER,7X10X380 702 702A07380 1
STAY,FR,LH,G.GRAY 35011 35011-1635-GD 1 CN
STAY,FR,LH,SILVER NO.35 35011B 35011-1635-VZ 1 CAUS
STAY,FR,RH,G.GRAY 35011C 35011-1636-GD 1 CN
STAY,FR,RH,SILVER NO.35 35011E 35011-1636-VZ 1 CAUS
STAY,RR,LH,G.GRAY 35011F 35011-1640-GD 1 CN
STAY,RR,LH,SILVER NO.35 35011H 35011-1640-VZ 1 CAUS
STAY,RR,RH,G.GRAY 35011I 35011-1641-GD 1 CN
STAY,RR,RH,SILVER NO.35 35011K 35011-1641-VZ 1 CAUS
GRIP,TAIL,P.P.BLACK MICA 46075C 46075-1104-20 1 CN
GRIP,TAIL,P.P.BLACK MICA 46075D 46075-1104-5M 1 CAUS
