1999 Ninja® ZX™-6R - Battery Case

DOWNLOAD PDF
SELECT A NEW PART
11012
11012
11012
11012
11050
11050
11050A
11050A
11050C
11050C
11050C
11050C
32037
32037
32046
32046
32046A
32046A
35011
35011
35011A
35011A
35011B
35011B
35011C
35011C
46075B
46075B
46075C
46075C
55020
55020
55020A
55020A
92015
92015
92015A
92015A
92015B
92015B
92072
92072
92072A
92072A
92072B
92072B
92072B
92072B
92093
92093
92093A
92093A
92150
92150
92150
92150
92150A
92150A
92150A
92150A
92150B
92150B
92150B
92150B
92150B
92150B
92150B
92150B
92151
92151
92151
92151
92151A
92151A
130A
130A
130A
130A
550
550
Part Item Information
ITEM NAME REF # PART NUMBER QUANTITY DESTINATION REMARKS
CAP,BUNGEE CORD HOOK 11012 11012-1589 2
BRACKET,TAIL GRIP 11050 11050-1645 1
BRACKET,IGNITER 11050A 11050-1649 1
BRACKET,TAIL GRIP 11050C 11050-1797 2
BRACKET-SHOCKABSORBER 32037 32037-1767 1
BRACKET-SEAT,RR,LH 32046 32046-1453 1
BRACKET-SEAT,RR,RH 32046A 32046-1454 1
STAY,FR,STEP,LH,SILVER 35011 35011-1874 1
STAY,FR,STEP,RH,SILVER 35011A 35011-1875 1
STAY,RR STEP,LH,SILVER 35011B 35011-1878-TX 1
STAY,RR STEP,RH,SILVER 35011C 35011-1879-TX 1
GRIP,RR,LH,F.BLACK 46075B 46075-1171-21 1
GRIP,RR,RH,F.BLACK 46075C 46075-1172-21 1
GUARD,FR STEP STAY,LH 55020 55020-1627 1
GUARD,FR STEP STAY,RH 55020A 55020-1628 1
NUT 92015 92015-1700 2
NUT,FLANGED,16MM 92015A 92015-1881 1
NUT,16MM 92015B 92015-1953 1
BAND,L=470 92072 92072-1331 1
BAND,U LOCK 92072A 92072-1355 1
BAND,L=122 92072B 92072-1363 2
SEAL,REAR GRIP,LH 92093 92093-1476 1
SEAL,REAR GRIP,RH 92093A 92093-1477 1
BOLT,SOCKET,8X20 92150 92150-1155 2
BOLT,SOCKET,8X40 92150A 92150-1735 2
BOLT,SOCKET,8X20 92150B 92150-1839 8
BOLT,6X28 92151 92151-1276 2
BOLT,6MM 92151A 92151-1334 2
BOLT-FLANGED,8X30 130A 130J0830 2
PIN-COTTER,4.0X25 550 550D4025 1
BOLT-FLANGED,6X16,BLACK 130 130J0616 5
BOLT-FLANGED,6X16,BLACK 130 130J0616 7
BRACKET,CANISTER 11050B 11050-1733 1
BRACKET-COMP,FUEL PUMP 23062 23062-1125 1
BRACKET-COMP,FUEL PUMP 23062A 23062-1127 1
