1999 Ninja® ZX™-9R - Battery Case

DOWNLOAD PDF
SELECT A NEW PART
130
130
130
130A
130A
130B
130B
11012
11012
11050
11050A
11050B
11050D
11050E
11050E
11050F
35011
35011A
35011B
35011C
46075B
46075C
55020
55020A
92015
92072
92072A
92072A
92072B
92072C
92072C
92072C
92072C
92150
92150
92150
92150
92150A
92150A
92150B
92150B
92150B
92150B
92151
92152
92152
92152
92152
92160
92160
Part Item Information
ITEM NAME REF # PART NUMBER QUANTITY DESTINATION REMARKS
BOLT-FLANGED,6X16,BLACK 130 130J0616 3
BOLT-FLANGED 130A 130J0812 2
BOLT-FLANGED,8X30 130B 130J0830 2
CAP,BUNGEE CORD HOOK 11012 11012-1589 2
BRACKET,FUEL FILTER 11050 11050-1471 1
BRACKET,RR SEAT&HELMET,LH 11050A 11050-1472 1
BRACKET,RR SEAT&HELMET,RH 11050B 11050-1475 1
BRACKET,FUEL PUMP 11050D 11050-1501 1
BRACKET,TAIL GRIP 11050E 11050-1797 2
BRACKET,TAIL GRIP 11050F 11050-1871 1
STAY,FR STEP,LH 35011 35011-1874 1
STAY,FR STEP,RH 35011A 35011-1875 1
STAY,RR STEP,LH,SILVER 35011B 35011-1878-TX 1
STAY,RR STEP,RH,SILVER 35011C 35011-1879-TX 1
GRIP,RR,LH,F.BLACK 46075B 46075-1171-21 1
GRIP,RR,RH,F.BLACK 46075C 46075-1172-21 1
GUARD,FR STEP STAY,LH 55020 55020-1627 1
GUARD,FR STEP STAY,RH 55020A 55020-1628 1
NUT 92015 92015-1700 1
BAND,TOOL 92072 92072-1349 1
BAND,U LOCK 92072A 92072-1355 2
BAND,U LOCK 92072B 92072-1356 1
BAND,L=122 92072C 92072-1363 4
BOLT,FLANGED,6X30 92150 92150-1486 4
BOLT,SOCKET,8X40 92150A 92150-1735 2
BOLT,SOCKET,8X20 92150B 92150-1839 8
BOLT,6MM 92151 92151-1334 2
COLLAR 92152 92152-1108 4
DAMPER 92160 92160-1937 2
